| Items | P5 | P8 | P10 |
|---|---|---|---|
| Colour Configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| LED Type | SMD1921 | SMD3535 | SMD3535 |
| Brightness(nits) | 6000 | 6000 | 6000 |
| Pixel Pitch | 5mm | 8mm | 10mm |
| Pixel Density(pixel/m) | 4000 | 15625 | 10000 |
| Module Size(mm) | 320x160 | 320x160 | 320x160 |
| Pixels/Module(dots) | 64x32 | 40x20 | 32x16 |
| Cabinet Size(mm) | 960x960mm | ||
| Pixels/Cabinet(dots) | 192x192 | 120x120 | 96x96 |
| Cabinet Weight | 36kg | ||
| Viewing Distance | >5m | >8m | >10m |
| Max Power Consumption | 1000w/m | 1000w/m | 1000w/m |
| Average Power Consumption | 350w/m2 | 350w/m2 | 350w/m2 |
| Viewing Angle | H: 140°: V: 140° | H: 120°: V: 120° | H: 120°: V: 120° |
| Cabinet Material | Diecasting Aluminum | ||
| Cabinet Maintenance | Front & Rear Service | Front & Rear Service | Front & Rear Service |
| Refresh Rate | 2880-3840HZ | 2880-3840HZ | 2880-3840HZ |
| LED Life | 100.000 hours | 100.000 hours | 100.000 hours |
| Supply Voltage | AC100~240V(50-63Hz) | AC100~240V(50-63Hz) | AC100~240V(50-63Hz) |
| Working Temperature | -40°C~+70°C | ||
| Working Humidity | 10%-90%RH | ||
| Gray Scale | 16bit | ||
| IP Rating | IP65 | ||
| Color Temperature | 6500-9500k | ||
| Application Venue | Advertising publish, Retail store, Shopping mall, Display of Dishes, Welcome display, Self-service business, Exhibition hall, Wayfinding, Airport, Subway, Elevator, Restaurant & Hotel Supplies, Education, Medical Treatment, Stage Rental, Mall stage, Catwalk show, Stage background wall | ||
